EMISSION COLOUR CHIP MATERIAL EMISSION PEAK W.LENGTH	LENS COLOR/TYPE	PART NO.	Viewing Angle Degrees	IV (mcd) @ 20mA
				MIN	TYP
HI.EFF.RED	RED DIFFUSED	KL-33 HD	80	2	3
GaP/GaP	RED DIFFUSED	KL-33 HD	60	3	4
700nm	RED TRANSPARENT	KL-33 HT	50	8	10
	WATER CLEAR	KL-33 HC	50	8	10
HYPER RED	RED DIFFUSED	KL-33 HHD	80	10	15
GaAIAs/GaAs(SH)	RED DIFFUSED	KL-33 HHD	60	15	25
670nm	RED TRANSPARENT	KL-33 HHT	50	40	60
	WATER CLEAR	KL-33 HHC	50	40	60
HI.INT.RED	RED DIFFUSED	KL-33 ID	80	15	20
GaAsP/GaP	RED DIFFUSED	KL-33 ID	60	20	30
630nm	RED TRANSPARENT	KL-33 IT	50	60	80
	WATER CLEAR	KL-33 IC	50	60	80
GREEN	GREEN DIFFUSED	KL-33 GD	80	10	20
GaP/GaP	GREEN DIFFUSED	KL-33 GD	60	15	25
567nm	GREEN TRANSPARENT	KL-33 GT	50	40	70
	WATER CLEAR	KL-33 GC	50	40	70
YELLOW	YELLOW DIFFUSED	KL-33 YD	80	10	15
GaAsP/GaP	YELLOW DIFFUSED	KL-33 YD	60	15	25
590nm	YELLOW TRANSPARENT	KL-33 YT	50	40	60
	WATER CLEAR	KL-33 YC	50	40	60
AMBER	AMBER DIFFUSED	KL-33 AD	80	10	15
GaAsP/GaP	AMBER DIFFUSED	KL-33 AD	60	15	25
610nm	AMBER TRANSPARENT	KL-33 AT	50	40	60
	WATER CLEAR	KL-33 AC	50	40	60
HYPER INT.RED	RED DIFFUSED	KL-33 HID	80	30	50
GaAIAs/GaAs(SH)	RED DIFFUSED	KL-33 HID	60	50	80
660nm	RED TRANSPARENT	KL-33 HIT	50	150	200
	WATER CLEAR	KL-33 HIC	50	150	200
HYPER GREEN	GREEN DIFFUSED	KL-33 HGD	80	20	35
GaP/GaP	GREEN DIFFUSED	KL-33 HGD	60	35	50
567nm	GREEN TRANSPARENT	KL-33 HGT	50	70	120
	WATER CLEAR	KL-33 HGC	50	70	120
SUPERBRITE RED	RED DIFFUSED	KL-33 SRD	80	70	90
GaAIAs/GaAs(DH)	RED DIFFUSED	KL-33 SRD	60	100	150
660nm	RED TRANSPARENT	KL-33 SRT	50	300	400
	WATER CLEAR	KL-33 SRC	50	300	400
SUPERBRITE YELLOW-GREEN	GREEN DIFFUSED	KL-33 SYGD	80	70	90
AlGalnP/GaAs	GREEN DIFFUSED	KL-33 SYGD	60	90	120
570nm	GREEN TRANSPARENT	KL-33 SYGT	50	250	350
	WATER CLEAR	KL-33 SYGC	50	250	350
SUPERBRITE YELLOW	YELLOW DIFFUSED	KL-33 SYD	80	90	120
AlGalnP/GaAs	YELLOW DIFFUSED	KL-33 SYD	60	120	180
590nm	YELLOW TRANSPARENT	KL-33 SYT	50	300	500
	WATER CLEAR	KL-33 SYC	50	300	500
SUPERBRITE YELLOW-AMBER	AMBER DIFFUSED	KL-33 SYAD	80	90	120
AlGalnP/GaAs	AMBER DIFFUSED	KL-33 SYAD	60	120	180
595nm	AMBER TRANSPARENT	KL-33 SYAT	50	300	500
	WATER CLEAR	KL-33 SYAC	50	300	500
ULTRABRITE RED	WATER CLEAR	KL-33 URC	50	800	1000
GaAlAs/GaAs(DH)
650nm
ULTRABRITE YELLOW	WATER CLEAR	KL-33 UYC	50	600	800
AlGaInP/GaAs
590nm
ULTRABRITE YELLOW AMBER	WATER CLEAR	KL-33 UYAC	50	600	800
AlGaInP/GaAs
595nm
HIGH ULTRABRITE RED	WATER CLEAR	KL-33 HURC	50	900	1100
AlGaInP/GaAs
640nm
HIGH ULTRABRITE YELLOW	WATER CLEAR	KL-33 HUYC	50	800	1100
AlGaInP/GaAs
590nm
HIGH ULTRABRITE YELLOW AMBER	WATER CLEAR	KL-33 HUYAC	50	800	1100
AlGaInP/GaAs
595nm
SUPERBRITE BLUE	WATER CLEAR	KL-33 SBC(470)	50	120	250
InGaN/SiC
470nm
BLUE GREEN	WATER CLEAR	KL-33 BGC(505)	50	200	300
InGaN/SiC
505nm
GREEN	WATER CLEAR	KL-33 GBC(525)	50	250	400
InGaN/SiC
525nm
ULTRABRITE BLUE GREEN	WATER CLEAR	KL-33 UBGC(505)	50	400	600
InGaN/SiC
505nm
ULTRABRITE GREEN	WATER CLEAR	KL-33 UGBC(525)	50	500	800
InGaN/SiC
525nm
